Intel® Xeon® Gold
Intel® Xeon® Gold processors bring high performance among with the newest security technologies that are even more efficient when working with your data. The Gold series supports the maximum speed and capacity of DDR4 memories and is scalable for up to 4-socket setups even with the 5000 family. Thanks to this, it significantly moves the boundaries of the mid-tier performance segment compared to the previous generation of server processors.
Processor
Processor manufacturer: Intel
Processor generation: 3rd Generation Intel® Xeon® Scalable
Processor model: 6326
Processor base frequency: 2.9 GHz
Processor family: Intel® Xeon® Gold
Processor cores: 16
Processor socket: LGA 4189
Component for: Server/workstation
Processor lithography: 10 nm
Processor series: Intel Xeon Gold 6000 Series
Processor threads: 32
System bus rate: 11.2 GT/s
Processor operating modes: 64-bit
Processor boost frequency: 3.5 GHz
High priority cores: 4
High priority core frequency: 3 GHz
Low priority cores: 12
Low priority core frequency: 2.6 GHz
Processor cache: 24 MB
Thermal Design Power (TDP): 185 W
Processor codename: Ice Lake
Processor ARK ID: 215274
Memory
Memory types supported by processor: DDR4-SDRAM
Memory channels: Octa-channel
Feature: ECC
Graphics
On-board graphics card model: Not available
Discrete graphics card model: Not available
Features
Feature: Execute Disable Bit
Maximum number of PCI Express lanes: 64
PCI Express slots version: 4.0
Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512
Scalability: 2S
Feature: Embedded options available
Processor special features
Feature: Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology: 2.0
Feature: Intel® AES New Instructions (Intel® AES-NI)
Feature: Intel Trusted Execution Technology
Feature: Intel® Speed Shift Technology
Feature: Intel® Transactional Synchronization Extensions
Feature: Intel® Total Memory Encryption
Feature: Intel® Crypto Acceleration
Feature: Intel® Platform Firmware Resilience Support
Maximum Enclave Size Support for Intel® SGX: 64 GB
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel Software Guard Extensions (Intel SGX)
Feature: Intel 64
Feature: Intel Virtualization Technology (VT-x)
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
AVX-512 Fused Multiply-Add (FMA) units: 2
Feature: Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Feature: Intel® Resource Director Technology (Intel® RDT)
Feature: Intel® Volume Management Device (VMD)
Feature: Intel® Run Sure Technology
Feature: Mode-based Execute Control (MBE)
Feature: Intel® Optane™ DC Persistent Memory Supported
Operational conditions
Tcase: 78 °C
Technical details
Target market: Cloud Computing
Launch date: Q2'21
Status: Launched
Supported memory types: DDR4-SDRAM
Memory speed (max): 3200 MHz
Number of UPI links: 3
Servicing status: Baseline Servicing
Other features
Maximum internal memory: 6 TB
Supermicro Intel Xeon Gold 6326. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4189, Processor lithography: 10 nm. Memory channels: Octa-channel, Memory types supported by processor: DDR4-SDRAM. Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: 2S. Maximum Enclave Size Support for Intel® SGX: 64 GB. Maximum internal memory: 6 TB
Super Micro
MBR CODE - P4X-ICX6326-SRKXK
EAN - 0672042456185
