Display
Display diagonal: 95.2 cm (37.5")
Display resolution: 3840 x 1600 pixels
HD type: UltraWide Quad HD+
Native aspect ratio: 24:10
Display technology: LED
Panel type: IPS
Backlight type: LED
Display brightness (typical): 300 cd/m²
Response time: 5 ms
Screen shape: Curved
Screen curvature rating: 2300R
Contrast ratio (typical): 1000:1
Maximum refresh rate: 60 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.229 x 0.229 mm
Pixel density: 111 ppi
Viewable size, horizontal: 88 cm
Viewable size, vertical: 36.6 cm
Viewable size diagonal: 95.3 cm
Digital horizontal frequency: 31 - 99 kHz
Digital vertical frequency: 29 - 31 Hz
Colour gamut standard: sRGB
Performance
Feature: Flicker-free technology
Feature: Low Blue Light technology
Multimedia
Number of speakers: 2
RMS rated power: 2 W
Feature: Built-in speaker(s)
Design
Market positioning: Business
Product colour: White
Ports & interfaces
Feature: Built-in USB hub
USB hub version: 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type: USB Type-B, USB Type-C
Number of USB Type-B upstream ports quantity: 2
Number of USB Type-C upstream ports quantity: 1
USB Type-A downstream ports quantity: 4
Feature: USB Type-C DisplayPort Alternate Mode
Feature: HDMI
HDMI ports quantity: 2
DisplayPorts quantity: 1
Feature: Headphone out
Headphone outputs: 1
Headphone connectivity: 3.5 mm
Feature: Built-in KVM switch
Feature: HDCP
Network
Feature: Ethernet LAN
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Height adjustment
Adjustable height (max): 19.3 cm
Feature: Swivelling
Swivel angle range: -70 - 70°
Feature: Tilt adjustment
Tilt angle range: -5 - 35°
Feature: On Screen Display (OSD)
On Screen Display (OSD) languages: German, English, Spanish, French, Italian, Swedish
Power
Energy efficiency class (SDR): E
Energy consumption (SDR) per 1000 hours: 29 kWh
Power consumption (typical): 29 W
Power consumption (standby): 0.5 W
Power consumption (max): 194 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 356891
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 20 - 80%
Storage relative humidity (H-H): 10 - 90%
Weight & dimensions
Width (with stand): 893.9 mm
Depth (with stand): 240 mm
Height (with stand): 411 mm
Weight (with stand): 13.2 kg
Width (without stand): 893.9 mm
Depth (without stand): 109.8 mm
Height (without stand): 398.2 mm
Weight (without stand): 9.5 kg
Packaging content
Feature: Stand included
Cables included: AC, DisplayPort, HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C
Feature: Quick start guide
Sustainability
Feature: Sustainability compliance
Sustainability certificates: ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO
Other features
Feature: Picture-by-Picture (PbP)
Compliance certificates: CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE
Ethernet LAN data rates: 10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports: 1
Logistics data
Harmonized System (HS) code: 85285210
EIZO FlexScan EV3895-WT. Display diagonal: 95.2 cm (37.5"), Display resolution: 3840 x 1600 pixels, HD type: UltraWide Quad HD+, Display technology: LED, Response time: 5 ms, Native aspect ratio: 24:10, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: White
Eizo
MBR CODE - EV3895-WT
EAN - 4995047056744
Display diagonal | 95.2 cm (37.5") |
Display resolution | 3840 x 1600 pixels |
HD type | UltraWide Quad HD+ |
Native aspect ratio | 24:10 |
Display technology | LED |
Panel type | IPS |
Backlight type | LED |
Touchscreen | No |
Display brightness (typical) | 300 cd/m² |
Response time | 5 ms |
Screen shape | Curved |
Screen curvature rating | 2300R |
Supported graphics resolutions | 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3440 x 1440, 3840 x 1600 |
Contrast ratio (typical) | 1000:1 |
Maximum refresh rate | 60 Hz |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Display number of colours | 16.78 million colours |
Pixel pitch | 0.229 x 0.229 mm |
Pixel density | 111 ppi |
Viewable size, horizontal | 88 cm |
Viewable size, vertical | 36.6 cm |
Viewable size diagonal | 95.3 cm |
Digital horizontal frequency | 31 - 99 kHz |
Digital vertical frequency | 29 - 31 Hz |
Colour gamut standard | sRGB |
NVIDIA G-SYNC | No |
AMD FreeSync | No |
Flicker-free technology | Yes |
Low Blue Light technology | Yes |
Number of speakers | 2 |
RMS rated power | 2 W |
Built-in speaker(s) | Yes |
Market positioning | Business |
Product colour | White |
Built-in USB hub | Yes |
USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
USB upstream port type | USB Type-B, USB Type-C |
Number of USB Type-B upstream ports quantity | 2 |
Number of USB Type-C upstream ports quantity | 1 |
USB Type-A downstream ports quantity | 4 |
USB Type-C DisplayPort Alternate Mode | Yes |
DVI port | No |
HDMI | Yes |
HDMI ports quantity | 2 |
DisplayPorts quantity | 1 |
Headphone out | Yes |
Headphone outputs | 1 |
Headphone connectivity | 3.5 mm |
Built-in KVM switch | Yes |
HDCP | Yes |
Ethernet LAN | Yes |
VESA mounting | Yes |
Panel mounting interface | 100 x 100 mm |
Cable lock slot | Yes |
Cable lock slot type | Kensington |
Height adjustment | Yes |
Adjustable height (max) | 19.3 cm |
Swivelling | Yes |
Swivel angle range | -70 - 70° |
Tilt adjustment | Yes |
Tilt angle range | -5 - 35° |
On Screen Display (OSD) | Yes |
On Screen Display (OSD) languages | German, English, Spanish, French, Italian, Swedish |
Energy efficiency class (SDR) | E |
Energy consumption (SDR) per 1000 hours | 29 kWh |
Power consumption (typical) | 29 W |
Power consumption (standby) | 0.5 W |
Power consumption (max) | 194 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Energy efficiency scale | A to G |
European Product Registry for Energy Labelling (EPREL) code | 356891 |
Operating temperature (T-T) | 5 - 35 °C |
Storage temperature (T-T) | -20 - 60 °C |
Operating relative humidity (H-H) | 20 - 80% |
Storage relative humidity (H-H) | 10 - 90% |
Width (with stand) | 893.9 mm |
Depth (with stand) | 240 mm |
Height (with stand) | 411 mm |
Weight (with stand) | 13.2 kg |
Width (without stand) | 893.9 mm |
Depth (without stand) | 109.8 mm |
Height (without stand) | 398.2 mm |
Weight (without stand) | 9.5 kg |
Stand included | Yes |
Cables included | AC, DisplayPort, HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
Quick start guide | Yes |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR, EPEAT Climate +, EPEAT Silver, TCO |
Picture-by-Picture (PbP) | Yes |
Compliance certificates | CB, CCC, CE, China RoHS, Federal Communications Commission (FCC), GS mark, ICES, PSE, RCM, RoHS, cTUVus, UKCA, VCCI, WEEE |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN (RJ-45) ports | 1 |
Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC |
Harmonized System (HS) code | 85285210 |
