The Chieftec CLASSIC Series brings new life to the proven quality and the decade-old success of the Chieftec cases with a fresh front panel design on the outside, while upgrading the quality and features on the inside.
Built from 0.7 mm sturdy SECC and including toolless drive installation kits, the CLASSIC series is perfect for system builders who value true quality and timeless design.
Design
Material: SECC
Form factor: Tower
Type: PC
Product colour: Black
Supported motherboard form factors: ATX, micro ATX, Mini-ITX
Number of 3.5" bays: 4
Number of 5.25" bays: 1
Number of 2.5" bays: 1
Number of expansion slots: 7
Feature: Reset button
Feature: On/off button
Maximum CPU cooler height: 16.5 cm
Maximum graphics card length: 40 cm
Power supply
Supported power supply form factors: ATX
Ports & interfaces
Feature: Audio input
Feature: Audio output
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Cooling
Number of front fans supported (max): 1
Front fans diameters supported: 90,120 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 80,90,120 mm
Storage
Supported HDD sizes: 2.5,3.5"
Weight & dimensions
Width: 198 mm
Depth: 490 mm
Height: 437 mm
Weight: 6.89 kg
Material thickness: 0.7 mm
Packaging data
Package weight: 7.82 kg
Logistics data
Harmonized System (HS) code: 84733080
Chieftec CM-25B-OP. Form factor: Tower, Type: PC, Product colour: Black. Supported power supply form factors: ATX. Front fans diameters supported: 90,120 mm, Rear fans diameters supported: 80,90,120 mm. Supported HDD sizes: 2.5,3.5". Width: 198 mm, Depth: 490 mm, Height: 437 mm
Chieftec
MBR CODE - CM-25B-OP
EAN - 0753263077103
