ROG Strix GeForce RTX™ 5070 Ti
FIND YOUR EDGE
The premium performance ROG Strix GeForce RTX 5070 Ti, featuring advanced cooling system with axial-tech fan, vapor chamber, phase-change GPU thermal pad and MaxContact design, lowering GPU temperature to reach higher performance. Aura sync provides endless possibilities for personalization with color or functional effects.
Cooling Expertise
Axial-tech Upgrades
Bigger and better. Axial-tech fans spin on dual-ball bearings and have been scaled up to propel more air through the card, setting the stage for lower temperatures, less noise, and higher performance.
Reverse Rotation and 0dB Technology
The two side fans spin counterclockwise to reduce turbulence and improve airflow through the heatsink. All three fans stop when GPU temperatures are below 50°C, ensuring quiet operation during light tasks or less-demanding games. They resume operation above 55°C, following a speed curve that optimizes performance and noise levels.
Vapor Chamber
A vapor chamber and heatsink soaks up heat from the graphics card, helping to ensure premium performance in a variety of scenarios.
Vented Backplate
Large backplate vents significantly enhance heat dissipation, helping to keep the GPU cooler during intense tasks. This additional airflow helps ensure optimal temperatures, boosting performance, longevity and stability by defending against overheating and thermal throttling.
A shorter PCB with optimized component and trace layouts reduces power loss and allows heat to escape through a large backplate vent.
MaxContact Design
MaxContact is an ASUS-exclusive manufacturing technique that effectively increases the surface area of the GPU heat spreader by 5% for improved thermal efficiency.
Phase-Change GPU Thermal Pad
By melting to effectively fill the gaps between the GPU and the thermal module, a premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
Processor
Feature: CUDA
CUDA cores: 8960
Graphics processor family: NVIDIA
Graphics processor: GeForce RTX 5070 Ti
Processor boost clock speed: 2602 MHz
Processor frequency (OC mode): 2625 MHz
Maximum resolution: 7680 x 4320 pixels
Parallel processing technology support: Not supported
Maximum displays per videocard: 4
Memory
Discrete graphics card memory: 16 GB
Graphics card memory type: GDDR7
Memory bus: 256 bit
Data transfer rate: 28 Gbit/s
Ports & interfaces
Interface type: PCI Express 5.0
HDMI ports quantity: 2
HDMI version: 2.1b
DisplayPorts quantity: 3
DisplayPort version: 2.1b
Performance
OpenGL version: 4.6
Feature: Virtual Reality (VR) ready
Feature: HDCP
HDCP version: 2.3
Feature: NVIDIA G-SYNC
NPU performance up to: 1406 TOPs
Feature: Overclocked (OC) edition
Design
Cooling type: Active
Cooling technology: ASUS Axial-tech
Number of fans: 3 fan(s)
Form factor: Full-Height/Full-Length (FH/FL)
Number of slots: 3.2
Feature: Illumination
Illumination colour: Multi
Product colour: Multicolour
Power
Minimum system power supply: 850 W
Supplementary power connectors: 1x 16-pin
Weight & dimensions
Weight: 1.67 kg
Length: 332 mm
Depth: 64 mm
Height: 147.3 mm
Packaging data
Package width: 420 mm
Package depth: 226 mm
Package height: 126 mm
Package weight: 2.64 kg
Package type: Box
Packaging content
Feature: Manual
ASUS ROG -STRIX-RTX5070TI-O16G-GAMING. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 5070 Ti. Discrete graphics card memory: 16 GB, Graphics card memory type: GDDR7, Memory bus: 256 bit. Maximum resolution: 7680 x 4320 pixels. OpenGL version: 4.6. Interface type: PCI Express 5.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Multi
ASUS
MBR CODE - 90YV0M90-M0NA00
EAN - 4711387920633
