El CTE C700 Air, un chasis semitorre E-ATX especialmente diseñado de la nueva serie CTE, fue diseñado para ofrecer una eficiencia térmica óptima y un flujo de aire máximo, garantizando así la refrigeración adecuada de los componentes críticos de su equipo. Para lograrlo, el CTE C700 Air admite un radiador AIO de hasta 420 mm, tanto en la parte frontal como en la trasera. Incluye tres ventiladores CT140 de 140 mm preinstalados.
Factor de forma CTE
Diseñado por Thermaltake
El factor de forma CTE, diseñado por Thermaltake, significa Eficiencia Térmica Centralizada y se centra en proporcionar un alto rendimiento térmico a los componentes críticos. El diseño utiliza una rotación de 90 grados de la placa base, lo que proporciona vías de aire más eficientes.
Dado que la CPU se ha acercado mucho más al panel frontal y la tarjeta gráfica al panel trasero, se proporciona una inducción de aire frío independiente para la disipación térmica de la CPU y la tarjeta gráfica, respectivamente. Este enfoque general ha permitido a CTE proporcionar un flujo de aire de entrada mejor y más eficiente mediante la ubicación de los componentes principales y la refrigeración, así como la optimización de la extracción de calor del sistema.
El CTE C700 es un nuevo modelo de la serie de formato CTE, que utiliza eficiencia térmica centralizada y se centra en proporcionar altos niveles de rendimiento térmico a los componentes críticos.
El diseño utiliza una rotación de 90 grados de la placa base, lo que proporciona vías de flujo de aire más eficientes.
Acerque las fuentes de calor críticas (CPU y tarjetas gráficas) al aire frío
Dado que la ubicación de la CPU del CTE C700 se ha movido mucho más cerca del panel frontal y la tarjeta gráfica se ha movido más cerca del panel trasero, se proporciona una inducción de aire frío independiente para la disipación térmica de la CPU y la tarjeta gráfica respectivamente.
Refrigeración activa para un flujo de aire de admisión más eficiente
Este enfoque general ha permitido que el CTE C700 proporcione un flujo de aire de admisión mejor y más eficiente a través de la ubicación de los componentes principales y la refrigeración, así como la optimización de la extracción de calor del sistema.
Un equilibrio perfecto entre estética y funcionalidad
El CTE C700 Air, un chasis de torre media E-ATX especialmente diseñado de la nueva serie de formato CTE, fue diseñado para brindar una eficiencia térmica óptima y un flujo de aire máximo, garantizando así la refrigeración adecuada de los componentes críticos de su equipo. Para lograrlo, el CTE C700 Air admite un radiador AIO de hasta 420 mm, tanto en la parte frontal como en la trasera. Viene con tres ventiladores CT140 de 140 mm preinstalados y admite un radiador AIO de hasta 420 mm tanto en la parte frontal como en la trasera. Su diseño de doble cámara permite exhibir los componentes clave y ofrece amplio espacio para soluciones de refrigeración de alta gama, con capacidad para alojar hasta doce ventiladores de 120 mm (once de 140 mm) dentro del chasis gracias a los soportes frontal, inferior, trasero y derecho, así como a la rejilla de ventilación superior. También cuenta con numerosos detalles interesantes, como dos ranuras PCI-E diferentes, filtros extraíbles, un soporte para bomba y depósito, y correas de velcro para facilitar la gestión de cables. Ya sea que sea un entusiasta de las PC o esté buscando un gabinete con refrigeración líquida personalizado, ¡prepárese para sorprenderse con el CTE C700 Air!
Crea y exhibe la construcción de tus sueños
Diseñado para adaptarse a tu vista, el CTE C700 Air incluye un panel de vidrio templado de 4 mm ubicado a la izquierda del chasis. Muestra todo, desde circuitos de refrigeración líquida personalizados hasta elegantes AIO y ventiladores. Para facilitar la extracción del vidrio templado, cuenta con una pequeña pestaña en la esquina superior izquierda y, para mantenerlo en su lugar, el panel se encaja mediante ganchos, también presentes en el resto de los paneles del chasis.
Soporte máximo del radiador
El CTE C700 ofrece múltiples ubicaciones de montaje y amplio espacio para crear tus propias configuraciones. Se pueden instalar radiadores DIY de hasta 360 mm de longitud en la parte frontal, trasera e inferior, y para compatibilidad con AIO, se pueden instalar radiadores de hasta 420 mm/360 mm en la parte frontal y trasera, lo que ofrece a los entusiastas de PC una gran flexibilidad para crear su configuración ideal.
¡Todos los componentes de refrigeración de sus sueños pueden caber!
El CTE C700 cuenta con una enorme capacidad para instalar ventiladores y disipadores: hasta doce ventiladores de 120 mm (once de 140 mm) y disipadores AIO de 360 mm/420 mm en la parte frontal y trasera. Además, los soportes para ventiladores en la parte frontal, trasera, inferior y lateral derecho, y el punto de instalación en la parte superior, garantizan una fácil instalación de todos los componentes de refrigeración que necesite.
Sorprenda su mundo con tres ventiladores CT140 de 140 mm preinstalados
El chasis de torre media CTE C700 Air cuenta con tres ventiladores PWM de 140 mm en la parte frontal, superior y trasera. Los CT140 son los ventiladores de caja de mayor rendimiento de la colección Thermaltake hasta la fecha.
¡Unifica a tus fans con tu construcción!
Thermaltake lanza los nuevos ventiladores de la serie CT, que permiten a los usuarios elegir entre negro o blanco, RGB o no RGB, para combinar con cualquier esquema de colores que tenga.
Lo hemos probado todo para que usted no tenga que hacerlo
En Thermaltake, siempre sometemos nuestros productos a pruebas de estrés en condiciones rigurosas para garantizar su calidad. El chasis CTE C700 Air Mid Tower se probó al 100 % de carga completa durante 30 minutos, con la CPU, la GPU y la placa base de gama alta en el momento de la prueba, y con una configuración de consumo, lo que nos permitió comprobar su rendimiento en situaciones reales.
Flujo de aire masivo y rendimiento increíble
Imágenes térmicas tomadas durante las pruebas térmicas. Gracias a su diseño CTE y a los tres ventiladores de refrigeración para PC CT140 preinstalados, pudimos garantizar que el CTE C700 Air tenga un flujo de aire excepcional, lo que garantiza un rendimiento de refrigeración excepcional que mantiene la temperatura interna baja y estable, utilizando componentes de alta gama.
Muéstralo a tu manera
Equipada con dos ranuras PCI-E diferentes, la CTE C700 Air permite montar la tarjeta gráfica horizontal o verticalmente, creando un amplio espacio para el sistema. Si prefiere instalar la tarjeta gráfica verticalmente, incluye un soporte adicional para cable vertical que permite una instalación de 90 o 180 grados.
Oportunidades de expansión de alto nivel
El CTE C700 Air ofrece una excelente capacidad de expansión, lo que le permite construir el sistema más sofisticado que pueda imaginar. Admite una placa base E-ATX (12"x13"), un disipador de CPU con una altura máxima de 190 mm, espacio libre para tarjetas gráficas de hasta 410 mm sin radiador, una fuente de alimentación de hasta 220 mm y hasta seis SSD de 2,5" o siete HDD de 3,5". Optimizado para una excelente capacidad de refrigeración, el CTE C700 Air admite hasta doce ventiladores de 120 mm u once de 140 mm, y disipadores AIO de 360 mm/420 mm en la parte frontal y trasera, lo que ofrece a los entusiastas de PC numerosas opciones y flexibilidad para organizar su configuración.
La cantidad de almacenamiento depende totalmente de usted
Para la compatibilidad de almacenamiento, el CTE C700 Air ofrece soporte máximo de hasta 7 HDD de 3,5” o 6 SSD de 2,5”.
Protección perfecta contra el polvo
Hay filtros finos extraíbles en la parte superior, frontal, inferior, trasera y lateral derecha del chasis para proporcionar una excelente protección contra el polvo, y son fácilmente extraíbles para su limpieza.
Todo lo que necesitas está ubicado en un solo lugar
Dos puertos USB 3.0, un USB 3.2 Gen 2 Tipo-C y puertos de audio HD están ubicados en el panel superior para otorgar acceso directo cuando sea necesario.
Diseño
Material: ABS, acero
Factor de forma: Torre Midi
Tipo: PC
Color del producto: Negro
Factores de forma de placa base compatibles: ATX, EATX, micro ATX, Mini-ITX
Número de bahías de 3,5": 7
Número de bahías de 2,5": 6
Número de ranuras de expansión: 7
Característica: Ventana lateral
Característica: Iluminación
Color de iluminación: Multi
Ubicación de la iluminación: Ventiladores de caja
Característica: Panel(es) de vidrio templado
Característica: Filtro antipolvo
Característica: Gestión de cables
Característica: Botón de reinicio
Característica: Botón de encendido/apagado
Altura máxima del disipador de CPU: 19 cm
Longitud máxima de la tarjeta gráfica: 41 cm
Longitud máxima de la fuente de alimentación: 22 cm
Puertos e interfaces
Cantidad de puertos USB 3.2 Gen 1 (3.1 Gen 1) Tipo A: 2
Cantidad de puertos USB tipo C: 1
Cantidad de puertos USB 3.2 Gen 2 (3.1 Gen 2) Tipo-C: 1
Característica: Puerto combinado para auriculares y micrófono
Enfriamiento
Ventiladores frontales instalados: 1x 140 mm
Número de ventiladores frontales admitidos (máximo): 3
Diámetros de ventiladores frontales soportados: 120, 140, 200 mm
Número de ventiladores laterales admitidos (máximo): 1
Diámetros de ventiladores laterales admitidos: 120,140 mm
Ventiladores traseros instalados: 1x 140 mm
Número de ventiladores traseros admitidos (máximo): 3
Diámetros de ventiladores traseros admitidos: 120,140 mm
Ventiladores superiores instalados: 1x 140 mm
Número de fans superiores admitidos (máximo): 2
Diámetros de ventiladores superiores admitidos: 120,140 mm
Número de ventiladores inferiores admitidos (máximo): 3
Diámetros de ventiladores inferiores soportados: 120,140 mm
Velocidad del ventilador: 0 - 1500 RPM
Tamaños de radiador delantero admitidos: 120, 140, 240, 280, 360, 420 mm
Tamaños de radiador inferior admitidos: 120, 140, 240, 280, 360 mm
Tamaños de radiador trasero admitidos: 120, 140, 240, 280, 360, 420 mm
Almacenamiento
Tamaños de disco duro compatibles: 2,5, 3,5"
Contenido del embalaje
Característica: Manual
Peso y dimensiones
Ancho: 566,5 mm
Profundidad: 327,6 mm
Altura: 505,5 mm
Peso: 15,6 kg
Thermaltake CTE C700 Air. Formato: Torre Midi. Tipo: PC. Color: Negro. Ventiladores frontales instalados: 1 de 140 mm. Diámetros de ventiladores frontales compatibles: 120, 140 y 200 mm. Diámetros de ventiladores laterales compatibles: 120 y 140 mm. Tamaños de disco duro compatibles: 2,5 y 3,5". Ancho: 566,5 mm, Profundidad: 327,6 mm, Altura: 505,5 mm.
Thermaltake CTE C700 Aire
